Product Description
Automann 122.281104.03 Camshaft LH
The Automann 122.281104.03 Left-Hand Camshaft is a fleet-standard component built for Meritor Q+ brake systems. Featuring a 1.188" head type and 1.5"-28 spline, this camshaft measures 11.125 inches in length and is compatible with several Meritor steer and drive axle configurations. Ideal for heavy-duty braking applications requiring OE-quality fit and durability.
Key Features
- Left-hand S-camshaft for Meritor Q+ applications
- Fits 16.5" x 5", 6", 7", and 8-5/8" brake setups
- Head Style 7 with 1.188" Meritor Q+ type
- 1.500"-28 spline with 1.500" A/B journal diameters
- Supports FMSI 4707, 4720, 4715A, and 4728 specs
- Compatible with standard and offset spider repair kits
Specifications
- Brand: Automann
- Part Number: 122.281104.03
- Alternate #: 12228110403
- UPC: 889626011573
- Position: Left Hand (LH)
- Length: 11.125"
- Spline: 1.500"-28
- Journal Diameter A/B: 1.500"
- Head Type: 1.188" Meritor Q+
- Head Style: 7
- Weight: 7.6 lbs
- Package Dimensions: 15.5 x 4.23 x 2.625 in
- Shipping: Parcel friendly
Applications
- Meritor Steer Axle – 16.5" x 5" FMSI 4720 (Q+)
- Meritor Steer Axle – 16.5" x 6" FMSI 4715A / 4715 (Cast P+ / Q+)
- Meritor Drive Axle – 16.5" x 7" FMSI 4707 (Q+)
- Meritor Drive Axle – 16.5" x 8-5/8" FMSI 4728 (Cast P+)
Cross References
- Meritor: 2210A7099, 2210J7524, 2210Y7227
- Spicer: 18-517
- Volvo: 85102565, 85111897
- Reference: E-9659
Related Items
- Camshaft Repair Kit: Automann 110.2207 (Standard)
- Camshaft Repair Kit: Automann 110.2211 (Offset Spider)
Additional Info
Replace in pairs for best brake balance. Grease thoroughly during installation using high-temp brake grease. Confirm spline count and camshaft length prior to ordering.
