Product Description
Automann 120.101508.02 - Camshaft RH for Eaton
The Automann 120.101508.02 Right-Hand S-Camshaft is built for Eaton steer and drive axles using extended service (ES) brake systems. It matches Meritor Q+ geometry and Hendrickson HXS shoe compatibility and is engineered to meet OEM performance standards under Fleet Standard designation.
Key Features
- RH camshaft for Eaton steer and drive axles
- Compatible with 15" and 16.5" extended service brake systems
- 1.5"-10 spline configuration
- Built to fit Meritor Q+ and Hendrickson HXS applications
Specifications
- Brand: Automann
- Part Number: 120.101508.02
- UPC: 889626007767
- Application: Eaton
- Head Style: 6
- Head Type: 1.125" Extended Life, Hendrickson HXS
- Length (L): 15.250"
- Splines: 1.500"-10
- Journal Diameter A: 1.500"
- Journal Diameter B: 1.500"
- Weight: 9.9 lbs
- Package Dimensions: 22 x 4.437 x 2.687 inches
Applications
Compatible Eaton brake systems include:
- 15" x 4" – FMSI 4729 (Steer Axle)
- 15" x 6" – FMSI 4716 (Reduced Envelope)
- 15" x 8-5/8" – FMSI 4717
- 16.5" x 5"/6"/7" – FMSI 4719, 4725, 4708, 4709 (ES and ESII)
Cross References
- Eaton: 811407
- Meritor: R607284
- Euclid: E-10916
Additional Info
- Fleet Standard product level
- Arrival Date: April 2014
- Backed by Automann limited warranty
- Compatible with Repair Kit: 110.2005
