Product Description
CURT 58151 - 7-Way RV Blade Connector Socket
General Description:
CURT's 7-way round RV blade connector ensures a reliable electrical connection for various trailer functions, including tail lights, turn signals, electric brakes, reverse lights, and a 12-volt battery. Constructed from rust-free black plastic with a spring-loaded cover, it protects against dust and water. Designed as a female-end socket for the vehicle side, this connector is compatible with RV travel trailers and can be easily interchanged with other 7-way RV connectors.
Key Features
- Custom fit for specific vehicles
- Plug-and-play design for easy installation
- 7-way connector supports various trailer functions
- Durable construction for long-lasting use
- Weatherproof with protective cover
Specifications
| Specification | Details |
|---|---|
| Brand | CURT |
| Material | Blank |
| Part Type | 7-Way Connector |
| Weight (LBS) | 0.3 |
| Packing Dimensions (Inches) | |
| Length | 3 |
| Width | 9 |
| Height | 4 |
Instructions
- Gather tools: wire strippers, crimping tool, electrical tape.
- Ensure the vehicle is off and keys removed.
- Locate the wiring harness at the rear bumper.
- Strip 1/4 inch of insulation from each wire.
- Match each wire color to the corresponding terminal on the socket and crimp connections.
- Attach the socket to the vehicle using provided hardware.
- Ensure the dust cover is functional.
- Reconnect the vehicle battery and test each function.
