Product Description
Dexter 023-106-00 Electric Brake Assembly - Right Hand, 12"x2", 6K
The Dexter 023-106-00 Electric Brake Assembly is a reliable, right-hand side brake solution engineered for trailers with 6,000 lb axles. Designed for durability and consistent braking power, this 12"x2" manual-adjust electric brake fits standard 5-bolt mounting flanges and is compatible with 14.5" to 16" wheels. Ideal for heavy-duty use in commercial or agricultural trailers.
Key Features
- Dexter OEM electric brake assembly
- Manual adjust for cost-effective serviceability
- Fits standard 5-bolt brake mounting flanges
- Right-hand (passenger side) configuration
- Compatible with 6K axles using 12" drums
- Used with 14.5" to 16" trailer wheels
Specifications
- Brake Size: 12" diameter x 2" width
- Axle Rating: 6,000 lbs
- Mounting Pattern: 5-bolt
- Actuation: Electric, Manual Adjust
- Position: Right Hand (Passenger Side)
- UPC: 689541039528
- Weight: Approx. 13.9 lbs
- Shipping Dimensions: Approx. 9.84" x 5.51" x 5.12"
Applications
- Dexter 6K trailer axles
- Standard drum brake systems
- Utility trailers, livestock trailers, and flatbeds
Cross References
- Dexter: 23-106, K23-106-00
- Redneck: 23-106
- Other: 023-106-00
Additional Info
- Left-hand (driver side) version: Dexter 23-105
- Sold individually – order one per side
- Mounting hardware sold separately
