Product Description
Baldwin BF1289‑SP Fuel/Water Separator Spin‑On Filter
The Baldwin BF1289‑SP spin‑on fuel and water separator offers heavy-duty protection for diesel applications. It features a built-in M12 × 1.75 sensor port and drain, 4‑micron nominal and 13‑micron absolute filtration media, making it ideal for Caterpillar, Perkins, Challenger, and other equipment engines.
Key Features
- Fuel/water separation with integrated drain port
- Spin-on design for easy replacement
- 4 µ nominal / 13 µ absolute filtration efficiency
- M12 × 1.75 sensor port and integrated O-ring
- Features integral gasket and O-ring for leak-free seal
Specifications
- Brand: Baldwin
- Part Number: BF1289‑SP
- UPC: 00791440086852
- Thread Size: M22 × 1.5
- Sensor Port Thread: M12 × 1.75
- Outside Diameter: 3 11/16 in (93.7 mm)
- Length: 7 15/16 in (201.6 mm)
- Micron Rating: 4 µ nominal / 13 µ absolute
- Contains: Integral gasket and O‑ring
- Weight: Approximately 2 lbs
- Shipping Dimensions: 18 × 18 × 21 in
Applications
- Caterpillar, Challenger, Perkins equipment
- Compatible with Agco, Cat, Perkins cross‑reference numbers
- Engineered for diesel fuel systems requiring water separation
Cross References
- Agco 529435D1
- Caterpillar 2715076, 3087298, 3188064
- Perkins 2656F853
- Donaldson P553880, Fleetguard FS20052, WIX WF10000
Additional Information
- Made in the USA
- Meets heavy-duty on-highway, agricultural, construction, marine, and industrial fuel filtration needs
- Parcel-shippable—packaged in standard auto-accessory box
