Product Description
Baldwin BF1399‑SP Fuel/Water Separator Spin‑On Filter
The Baldwin BF1399‑SP Heavy-Duty Spin-On Fuel/Water Separator Filter is featuring a built-in drain valve and a sensor port. With a 1″-14 thread, 4¼″ diameter, and 7⅝″ height, it’s designed for Caterpillar equipment and other industrial applications.
Key Features
- Spin-on design with built-in drain and 9/16-18 sensor port
- Heavy-duty construction to remove both fuel contaminants and water
- Caterpillar-compatible (e.g. CAT 326-1644)
- Tab/keyless tool-free installation
Specifications
- Brand: Baldwin
- Part Number: BF1399-SP
- UPC: 791440084094
- Thread Size: 1″-14
- Sensor Port Thread: 9/16″-18
- Outside Diameter: 4¼″ (108 mm)
- Height: 7⅝″ (193.7 mm)
- Micron Rating: 10 µ absolute
- Country of Origin: USA
- Weight: ~2.3 lb (1.05 kg)
- Shipping Dimensions: ~6″ × 6″ × 10″
Applications
- Caterpillar equipment using part number 326-1644
- Heavy-duty trucks and off-highway machinery
- Compatible with industrial and construction engines
Cross References
- Caterpillar: 326‑1644
- Donaldson: P550626
- Fleetguard: FS19820
- Fram: PS10264
- WIX: 33606, 33787
- Hastings: FF1180SP, FF1186SP
- Luber-Finer: LFF6770, LFF6771SC
Additional Information
- High-efficiency filtering with water separation
- Furnished O‑ring must be installed on post to ensure proper seal
- Designed for easy, parcel-friendly shipping
