Product Description
Baldwin BF1385‑SPS Spin‑On Fuel/Water Separator Filter
The Baldwin BF1385‑SPS premium Spin‑On Fuel/Water Separator Filter is equipped with an integrated drain valve, M14 × 2.0 sensor port, and reusable sensor. Built for high-pressure fuel systems, it delivers advanced protection for Case, Cummins, and other heavy‑duty engines exposed to water and particulate contaminants.
Key Features
- Integrated drain valve and sensor port (M14 × 2.0)
- Includes reusable water-in-fuel sensor
- 10 µm absolute cellulose media for high-efficiency filtration
- Durable design for extended service intervals
- OEM-grade performance in demanding diesel applications
Specifications
- Brand: Baldwin
- Part Number: BF1385‑SPS
- UPC: 791440080843
- Outside Diameter: 3 11/16 in (93.7 mm)
- Height: 7 3/8 in (187.3 mm)
- Thread Size: 1″‑14
- Sensor Port Thread: M14 × 2.0
- Micron Rating: 10 µm absolute
- Furnished Gasket: ES24‑D
- Integral Gasket: G381‑A
- Weight: ~1.95 lb (0.88 kg)
- Shipping Dimensions: 7.87 × 3.7 × 3.66 in (20 × 9.4 × 9.3 cm)
- Country of Origin: USA
Applications
- Case IH and Case construction equipment
- Cummins diesel engines
- Heavy‑duty trucks, buses, and industrial equipment
- Agricultural and off‑road machinery
Cross References
- Case: 87356193
- Cummins: 3973233
- Fleetguard: FS19732
- Donaldson: P550848
- WIX: 33955
- Luber‑Finer: LFF9732
- SF‑Filter: SK3183
Additional Information
- Designed for high-pressure common-rail fuel systems
- Removes both water and particulates to prevent injector damage
- Manufactured under ISO 9001:2015 quality standards
