Product Description
Baldwin BF1223‑O Fuel/Water Separator Spin‑On Filter
The Baldwin BF1223‑O Spin-On Fuel/Water Separator featuring an open port for bowl installation, integral post-seal, and furnished gasket(s). Designed for heavy-duty applications—including Carrier-Transicold units, Ford trucks, and Hino compressors—it provides reliable water removal and fuel filtration.
Key Features
- Spin-on design with open bowl port (thread 3¾‑10 UNEF)
- Integral post-seal—no separate gasket needed
- Includes furnished gasket(s)
- Tool‑free tab/keyless installation
- Heavy-duty construction for extended service life
Specifications
- Brand: Baldwin
- Part Number: BF1223‑O
- UPC: 791440087354
- Outside Diameter: 4¼ in (108 mm)
- Height: 5⅛ in (132.6 mm)
- Thread Size: 1″‑14 UNF
- Bowl Port Thread: 3¾‑10 UNEF
- Country of Origin: USA
- Weight: ~1.9 lb (0.86 kg)
- Shipping Dimensions: ~4¼ × 4¼ × 5⅛ in
Applications
- Carrier‑Transicold refrigeration units
- Ford trucks (e.g., using F1HZ‑9365‑A / Motorcraft FD3368)
- Hino trucks & Ingersoll‑Rand compressors
Cross References
- Motorcraft FD3368
- Carrier: 30‑01079
- Fleetguard FS19931
- Donaldson P551056 / P550730
- WIX 33411
- Luber‑Finer LFF8063
Additional Information
- Cellulose media with 20 µ absolute rating
- ISO 9001 production quality
- Parcel‑friendly packaging
