Product Description
Baldwin BT260‑10 Low Pressure Hydraulic Spin‑On Filter
The Baldwin BT260‑10 Spin-On Hydraulic Filter is designed for use in low-pressure return or suction line circuits. Built with 10 micron cellulose media, this filter effectively removes harmful particulates to extend the life of hydraulic components and fluid systems.
Key Features
- Spin-on design for quick, clean filter changes
- 10 micron cellulose media for efficient particle capture
- Heavy-duty steel housing for strength and durability
- Designed for use in low pressure hydraulic circuits
- Includes integral bypass valve
Specifications
- Brand: Baldwin
- Part Number: BT260‑10
- UPC: 791440060319
- Type: Hydraulic Spin-On – Low Pressure
- Media: Cellulose
- Micron Rating: 10 µm nominal
- Thread Size: 1 1/8″-16
- Outside Diameter: 3.69 in (93.7 mm)
- Height: 5.44 in (138.2 mm)
- By-Pass Valve: Yes (typically 25 PSI)
- Furnished Gasket: Included
- Weight: ~1.4 lb (0.64 kg)
- Shipping Dimensions: 6 × 4 × 4 in (15.2 × 10.2 × 10.2 cm)
- Country of Origin: USA
Applications
- Return and suction lines in hydraulic circuits
- Skid steer and compact equipment hydraulics
- Agricultural and turf maintenance systems
- Light industrial fluid power units
Cross References
- Donaldson: P550260
- Fleetguard: HF3507
- WIX: 51411
- Luber-Finer: LH260
- Fram: P1119
Additional Information
- Replace per system monitoring or regular maintenance intervals
- Designed for compatibility with standard low pressure filter heads
- Meets or exceeds OEM performance standards
