Permatex 16067 - Bullseye Windshield Repair Kit, .17 FL OZ

Permatex

MSRP: $36.83
$20.11
(You save $16.72 )

SKU: 16067PER

Adding to cart… The item has been added
Fast and secure, low cost shipping.

Product Description

Permatex 16067 - Bullseye Windshield Repair Kit, .17 FL OZ

Permatex 16067 - Bullseye Windshield Repair Kit, .17 FL OZ

General Description:

Permatex Bullseye Windshield Repair Kit is the first one-component windshield repair system designed to be used by the car owner. Can be used to make air-tight repairs of bullseye damage up to 1 1/4″ in diameter on most laminated windshield glass. This all-in-one kit is safe and easy to use and requires no mixing, no heat, making the repair virtually undetectable.

Key Features
  • CONTENTS: Permatex® Windshield Repair Syringe & Plunger, Repair Compound NET 0.025 FL OZ (0.75 mL), 1 Adhesive Disc, 1 Pedestal, 1 Curing Strip, 1 Instruction Sheet. Additional tools recommended: Push Pin, Razor Blade.
  • All-in-one windshield repair system designed to be used by the car owner
  • May be used to make air-tight repairs of bullseye damage up to 1 1/4" in diameter on most laminated windshield glass
  • Safe and easy to use and makes repair virtually undetectable
  • Requires no mixing or heat
Specifications
Specification Details
Brand Permatex
Material Glass
Item Volume 7 Liters
Weight 1.55
Packing Dimensions (Inches)
Length 8
Width 4.75
Height 9
Instructions
  1. CLEAN out any loose glass particles from PIT (hole caused by striking object) of the break using push pin. Clean the area surrounding the break using a dry cloth or paper towel.
  2. PEEL backing off ONE side of adhesive seal. Line up hole in seal with PIT (tab pointing upward). Press seal to glass. Run fingers around seal to insure a tight bond.
  3. PEEL backing from TOP side of adhesive.
  4. Line up the pedestal with the adhesive seal making sure tabs match up. Press the pedestal to seal. Run fingers around pedestal to insure a tight bond.
  5. Cut tip off resin container (about 1/8 inch) to open stem. Place stem 1/4 inch into pedestal opening. Slowly squeeze resin tube, releasing resin into the pedestal. Continue squeezing resin tube and remove from pedestal. Wipe any excess resin from tip with cloth and SAVE empty container for Step 10.
  6. Press fit INJECTOR into pedestal. Insure that the connection is tight.
  7. Hold injector in one hand, pull plunger upward with other hand. LOCK plunger by ENGAGING LOWER notch in plunger with spring clip. Release hands and allow device to remain in locked position. LET SIT FOR 10 MINUTES then proceed to Step 8.
  8. Remove injector from pedestal momentarily (to let air in). Replace injector as in Step 6. DEPRESS plunger downward and ENGAGE UPPER notch with spring clip. LET SIT FOR A MINIMUM OF 20 MINUTES then proceed to Step 9.
  9. Remove injector and discard. Loosen the outer edges of pedestal with safety razor. Once top part of pedestal and seal is bent away from the glass, grip the pedestal tab as shown. SLOWLY pull tab away. WIPE and remove excess resin.
  10. Hold resin container in one hand and make ready the clear curing film in the other hand (as shown). Slowly squeeze the resin container applying a drop of resin in PIT. Place clear curing film over PIT holding resin in the PIT.
  11. Run safety razor lightly over clear film to vent out any air bubbles.
  12. Note: Ultra violet sun rays cure the resin. Park vehicle in direct sunlight for 15 minutes. (On hazy days park vehicle in sunlight for a minimum of 1 hour).
  13. NOTE: The repair may not completely remove blemish or permanently fill the pit.
Warning Description
  • This product can expose you to chemical which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
