CEC Industries 7528BP S-8 Miniature Lamp | 12V DC Index Bay 15d
The CEC Industries 7528BP is a miniature S-8 incandescent lamp designed for 12V DC applications with a bayonet base. This dual-filament bulb delivers 35 CP on the primary filament and 2.78 CP on the secondary filament, making it suitable for indicator and accent lighting in heavy-duty equipment and vehicles.
Key Features
- Dual-filament design with 35 CP primary and 2.78 CP secondary output
- 12V DC rated with 1.64A primary and 0.42A secondary current draw
- Bay 15d bayonet base for secure, tool-free installation
- S-8 miniature lamp form factor for compact mounting
- Sold as a quantity of 2 bulbs per package
Specifications
| Brand | CEC Industries Ltd. |
| Part Number | 7528BP |
| Weight | 0.06 lb |
| Dimensions (L × W × H) | 3.97 × 2.76 × 0.5 in |
| UPC | 014271013225 |
| Voltage | 12V DC |
| Amperage | 1.64A / 0.42A |
